Forestry Cutter Standard Tooth – Replaces Bobcat® 7023593

Heavy-duty aftermarket forestry mulcher tooth designed as a replacement for Bobcat® reference part number 7023593. The double-tipped carbide cutting design efficiently processes hard and soft wood, standing trees, brush and material lying on the ground.

The durable carbide tips provide long wear life in demanding forestry-clearing applications. The tooth works with the cutter drum’s spiral tooth arrangement, allowing the teeth to engage the material individually for smoother operation and reduced horsepower demand.

Product Specifications

• Reference Part Number: 7023593
• Product Type: Forestry cutter mulcher tooth
• Tooth Style: Standard double-tip carbide tooth
• Overall Length: Approximately 3-7/8 in.
• Bolt-Hole Size: 1/2 in.
• Mounting Threads: 1/2"-20
• Construction: Alloy-steel body with tungsten-carbide cutting tips
• Condition: New aftermarket replacement part
• Quantity: One tooth

Compatible Applications

Designed for select Bobcat® forestry cutter attachments, including applicable FRC50, FRC60 and FRC70 configurations that use reference tooth number 7023593.

• FRC50 – select units beginning with serial number ANR600110 and later
• FRC50 – select ATSY-series units
• FRC60 – select units beginning with serial number ANR500245 and later
• FRC60 – select ATV1-series units
• FRC70 – select units beginning with serial number B48D00101 and later

Serial-number breaks and rotor configurations can vary. Always verify the original tooth number and compare the dimensions and mounting design before ordering.

Product Features

• Double carbide tips efficiently cut through hard and soft wood
• Suitable for processing standing trees, brush and ground material
• Carbide cutting surfaces provide extended wear life
• Heavy-duty alloy body withstands demanding mulching conditions
• Direct aftermarket replacement for compatible 7023593 applications
• Individual tooth engagement supports smooth cutter-drum operation

Mounting Hardware

Mounting hardware is not included unless specifically stated in the selected product option. Depending on the rotor and holder configuration, this tooth may require 1/2"-20 mounting bolts, lock washers and spacer bushings.

Inspect the existing bolts, washers, spacers and tooth holders before installation. Replace worn or damaged mounting components as necessary.

Important Fitment Notice

Several forestry cutter teeth may have a similar appearance but use different body dimensions, bolt arrangements, spacers and serial-number applications.

Please review all product images carefully and measure your current mulcher tooth before ordering.

Confirm the following before purchase:

• OEM or reference part number
• Attachment model and serial number
• Overall tooth length and width
• Bolt-hole size and mounting-thread configuration
• Spacer and washer requirements
• Shape of the tooth holder and mounting surface

Contact Construction Parts PNW for fitment assistance. Please provide the attachment model, serial number, current tooth measurements and clear photos of the tooth and mounting location.

Warranty

Ground engaging tools are covered against premature breakage for 30 days from the original invoice date. Normal wear, improper installation, incorrect fitment, loose hardware, impact damage and use outside the intended application are not considered manufacturing defects.

Bobcat® is a registered trademark of its respective owner. The Bobcat® name and part number are used for identification and fitment-reference purposes only. This product is an aftermarket replacement and is not manufactured, sponsored or endorsed by Bobcat Company.
