SM04 Kennametal Heavy Wear Foundation Drilling Bit
SM04 Rotating Tungsten Carbide Pick – 22mm Shank
The SM04 rotating tungsten carbide pick is designed for trenching and other demanding ground-engaging applications. It features a durable carbide cutting tip, rotating body design and a 22mm-class shank for use with compatible toolholders.
Rotation during operation helps distribute wear around the carbide tip, supporting consistent cutting performance and longer service life. The SM04 uses a K706 carbide grade for demanding and abrasive cutting conditions.
SM04 Product Specifications
- ANSI Catalog ID: SM04
- Material Number: 1317495
- Product Type: Rotating tungsten carbide pick
- Nominal Shank Size: 22mm / 0.87 in.
- Carbide Grade: K706
- Application: Trenching and ground-engaging cutting systems
Dimensional Specifications
- Point Included Angle – Sigma: 88°
- Second Point Included Angle – Sigma B: 26°
- Tip Diameter – TD: 0.738 in.
- Tip Length – TL: 0.858 in.
- Gage Length – L1: 1.8807 in.
- Body Diameter, Workpiece Side – D2: 1.50 in.
- Shank/Bore Diameter – D: 0.865 in.
- Shank Length – LS: 1.65 in.
- Overall Length – OAL: 3.5307 in.
Product Features
- Rotating design helps distribute wear around the carbide cutting tip
- K706 carbide grade for demanding cutting conditions
- Large 0.738-inch carbide-tip diameter
- Extended 0.858-inch carbide-tip length
- 22mm-class shank for compatible toolholder systems
- Heavy-duty construction for trenching and ground-engaging applications
Applications
The SM04 may be used in compatible cutting systems for:
- Trenching machines
- Rock wheels
- Utility trenchers
- Construction cutting attachments
- Surface-cutting equipment
- Other equipment using a compatible 22mm pick holder
Important Fitment Information
Rotating carbide picks can have a similar appearance while using different shank diameters, carbide profiles, body dimensions, retainers and overall lengths. Verify the complete specifications of your existing pick and holder before ordering.
Please confirm the following before purchase:
- ANSI catalog ID
- Material number
- Shank diameter
- Shank length
- Overall length
- Body diameter
- Carbide-tip diameter and length
- Retainer and toolholder compatibility
Contact Construction Parts PNW for assistance identifying the correct cutting pick. Please provide the machine make and model, existing pick number, holder number and clear photos of the current pick and holder.
Ordering Information
This listing is for the SM04 configuration. Other SM-series variants may use the same general product images but have different material numbers, carbide-tip dimensions, cutting angles and overall measurements. Review the specifications for the selected variant carefully before ordering.
Kennametal® is a registered trademark of its respective owner. Brand names, catalog numbers and material numbers are used for identification and cross-reference purposes only.
| Material | Heavy |
| Sold As | 50 Piece Box |
| Brand | Kennametal |
| Material Number | 1317495 |
| Product Family | Trenching & Surface Miners |
| Product Type | Trenching Conical Pick |
| Kennametal Category | Conical |
| Application | Trenching & Surface Mining |
| Shank Size | 22 mm |
| Shank System | 22 mm System |
| Bucket Quantity | 50 |
| Pallet Quantity | 2500 |
| Weight: | 34.50 LBS |
