SM09 Rotating Tungsten Carbide Pick – 22mm Shank – Material 4143706

SM09 Rotating Tungsten Carbide Pick – 22mm Shank

The SM09 rotating tungsten carbide pick is designed for trenching and other demanding ground-engaging cutting applications. It features a narrow-bottom plug-style carbide tip for use across a variety of cutting conditions and a smooth retainer design for compatible 22mm toolholder systems.

The rotating design allows the pick to turn during operation, helping distribute wear around the carbide tip and maintain consistent cutting performance. The SM09 uses a K3560 carbide grade and a compact plug-tip profile for compatible construction and trenching systems.

SM09 Product Specifications

• ANSI Catalog ID: SM09
• Material Number: 4143706
• Product Type: Rotating tungsten carbide pick
• Retainer Style: Smooth retainer
• Tip Style: Narrow-bottom plug tip
• Nominal Shank Size: 22mm / 0.87 in.
• Carbide Grade: K3560
• Application: Trenching and varied cutting conditions

Dimensional Specifications

• Point Included Angle – Sigma: 75°
• Tip Diameter – TD: 0.639 in.
• Tip Length – TL: 0.882 in.
• Gage Length – L1: 1.6705 in.
• Body Diameter, Workpiece Side – D2: 1.50 in.
• Shank/Bore Diameter – D: 0.865 in.
• Shank Length – LS: 1.65 in.
• Overall Length – OAL: 3.3205 in.

Product Features

• Rotating design helps distribute wear around the carbide tip
• Narrow-bottom plug tip for a variety of cutting conditions
• K3560 carbide grade for demanding applications
• Smooth retainer design for compatible toolholder bores
• 22mm-class shank for compatible cutting systems
• Compact carbide-tip profile for controlled cutting performance
• Heavy-duty construction for trenching and ground engagement

Applications

The SM09 may be used in compatible cutting systems for:

• Trenching machines
• Rock wheels
• Utility trenchers
• Construction cutting attachments
• Surface-cutting equipment
• Other equipment using a compatible 22mm pick holder

Important Fitment Information

Rotating carbide picks may have a similar appearance while using different carbide-tip profiles, shank dimensions, body diameters, retainers and overall lengths. Verify the complete specifications of your current pick and toolholder before ordering.

Please verify the following before purchase:

• ANSI catalog ID
• Material number
• Shank diameter
• Shank length
• Overall length
• Body diameter
• Carbide-tip diameter and length
• Carbide-tip profile
• Retainer and toolholder compatibility

Contact Construction Parts PNW for assistance identifying the correct cutting pick. Please provide the machine make and model, current pick number, holder number and clear photos of the existing pick and holder.

Ordering Information

This listing is for the SM09 configuration. Other SM-series variants may use the same general product images but have different material numbers, carbide grades, tip profiles, cutting angles and overall dimensions. Carefully review the specifications listed for the selected variant before ordering.

Kennametal® is a registered trademark of its respective owner. Brand names, catalog numbers and material numbers are used for identification and cross-reference purposes only.
