SM03 Rotating Tungsten Carbide Pick – 22mm Shank – Wide Cap

SM03 Rotating Tungsten Carbide Pick – 22mm Shank

The SM03 rotating tungsten carbide pick is designed for trenching, excavation and other demanding ground-engaging applications. It features a smooth retainer for use with compatible 22mm toolholder systems and a wide-cap body design that helps reduce wear around the pick head and holder area.

The rotating design allows the cutting pick to turn during operation, helping distribute wear around the carbide tip for more consistent cutting performance and longer service life. The SM03 is manufactured with a durable K706 carbide tip for abrasive operating conditions.

SM03 Product Specifications

• ANSI Catalog ID: SM03
• Material Number: 5610736
• Product Type: Rotating tungsten carbide pick
• Retainer Style: Smooth retainer
• Cap Style: Wide cap for reduced head wear
• Nominal Shank Size: 22mm / 0.87 in.
• Application: Trenching and abrasive cutting conditions
• Carbide Grade: K706

Dimensional Specifications

• Point Included Angle – Sigma: 90°
• Second Point Included Angle – Sigma B: 22°
• Tip Diameter – TD: 0.625 in.
• Tip Length – TL: 0.54 in.
• Gage Length – L1: 1.745 in.
• Body Diameter, Workpiece Side – D2: 2.00 in.
• Shank/Bore Diameter – D: 0.865 in.
• Shank Length – LS: 1.65 in.
• Overall Length – OAL: 3.395 in.

Product Features

• Rotating design helps distribute wear evenly around the carbide tip
• Wide-cap body helps reduce wear around the pick head and holder
• Smooth retainer design for compatible toolholder bores
• 22mm-class shank for compatible trenching systems
• K706 carbide grade for demanding and abrasive cutting conditions
• Heavy-duty construction for trenching and ground-engaging applications

Applications

The SM03 may be used in compatible cutting systems for:

• Trenching machines
• Rock wheels
• Utility trenchers
• Construction cutting attachments
• Road and surface cutting equipment
• Other machines using a compatible 22mm pick holder

Important Fitment Information

Carbide picks with a similar appearance may use different shank diameters, cap diameters, carbide-tip profiles, retainers and overall dimensions. Verify the complete pick specifications and toolholder requirements before ordering.

Please confirm the following before purchase:

• ANSI catalog number
• Material number
• Shank diameter
• Shank length
• Overall length
• Body and cap diameter
• Carbide-tip diameter and profile
• Retainer and toolholder compatibility

Contact Construction Parts PNW for help identifying the correct cutting pick. Please provide the machine make and model, current pick number, holder number and clear photos of the existing pick and holder.

Ordering Information

This listing is for the SM03 configuration. Other SM-series picks may use the same general product images but have different cap diameters, material numbers, dimensions or application recommendations. Review the specifications listed for the selected variant before ordering.

Kennametal® is a registered trademark of its respective owner. Brand names, catalog numbers and material numbers are used for identification and cross-reference purposes.
