SM01 Rotating Tungsten Carbide Pick – 22mm Shank – Material 1010860

SM01 Rotating Tungsten Carbide Pick – 22mm Shank

The SM01 rotating tungsten carbide pick is designed for trenching, milling and other demanding ground-engaging applications. It features a smooth retainer design for use in compatible 22mm toolholder systems and a carbide tip intended for abrasive operating conditions.

The rotating design allows the cutting pick to turn during operation, helping distribute wear around the carbide tip and supporting more consistent cutting performance. The SM01 uses a 22mm nominal shank and is designed for compatible holders with the correct bore diameter and retaining system.

SM01 Product Specifications

• ANSI Catalog ID: SM01
• Material Number: 1010860
• Product Type: Rotating tungsten carbide pick
• Retainer Style: Smooth retainer
• Nominal Shank Size: 22mm / 0.87 in.
• Application: Trenching and abrasive cutting conditions
• Carbide Grade: K706

Dimensional Specifications

• Point Included Angle – Sigma: 90°
• Second Point Included Angle – Sigma B: 22°
• Tip Diameter – TD: 0.625 in.
• Tip Length – TL: 0.54 in.
• Gage Length – L1: 1.745 in.
• Body Diameter, Workpiece Side – D2: 1.50 in.
• Shank/Bore Diameter – D: 0.865 in.
• Shank Length – LS: 1.65 in.
• Overall Length – OAL: 3.395 in.

Product Features

• Rotating carbide pick helps distribute cutting-tip wear
• Designed for abrasive trenching and ground-engaging conditions
• 22mm-class shank for compatible toolholder systems
• Smooth retainer design supports secure installation and rotation
• K706 carbide grade provides durability in demanding applications
• Suitable for replacement of worn picks in compatible cutting assemblies

Applications

The SM01 may be used in compatible cutting systems for:

• Trenching machines
• Rock wheels
• Construction cutting attachments
• Utility trenchers
• Road and surface cutting equipment
• Other machines using a compatible 22mm pick holder

Important Fitment Information

Cutting picks with a similar appearance may use different shank diameters, body dimensions, carbide geometries, retainers and holder configurations. Verify the complete pick dimensions and holder requirements before ordering.

Please confirm the following:

• ANSI catalog number
• Material number
• Shank diameter
• Shank length
• Overall length
• Body diameter
• Carbide-tip diameter and profile
• Retainer and toolholder compatibility

Contact Construction Parts PNW for assistance identifying the correct cutting pick. Please provide the machine make and model, current pick number, holder number and clear photos of the existing pick and holder.

Ordering Information

This listing is for the SM01 configuration. Other SM-series variants may use the same general product image but have different dimensional specifications, carbide geometry or application recommendations. Review the specifications shown in the selected product listing before ordering.

Kennametal® is a registered trademark of its respective owner. Brand names, catalog numbers and material numbers are used for identification and cross-reference purposes.
